| Processor socket: | Socket AM4 |
| Compatible processor series: | 2nd Generation AMD Ryzen™ 7, 2nd Generation AMD Ryzen™ 3, AMD Ryzen™ 3, AMD Ryzen™ Threadripper™, AMD Ryzen™ 5, 2nd Generation AMD Ryzen™ 5, AMD Ryzen™ 7, AMD Ryzen™ Threadripper™: The Second Generation |
| Processor manufacturer: | AMD |
| Audio output channels: | 7.1 channels |
| Motherboard chipset: | AMD B450 |
| Audio chip: | Realtek ALC887-VD2 |
| Windows operating systems supported: | Windows 7 x64, Windows 10 x64 |
| Motherboard chipset family: | AMD |
| Motherboard form factor: | micro ATX |
| Number of memory slots: | 2 |
| Memory slots type: | DIMM |
| Supported memory types: | DDR4-SDRAM |
| Unbuffered memory: | Yes |
| Maximum internal memory: | 64 GB |
| Supported memory clock speeds: | 3000, 2400 MHz, 2800, 2133, 3200, 2666, 2933 |
| Width: | 244 mm |
| Depth: | 244 mm |
| Ethernet interface type: | Gigabit Ethernet |
| Ethernet LAN: | Yes |
| Wi-Fi: | No |
| Audio connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| Number of SATA III connectors: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| S/PDIF out connector: | Yes |
| USB 2.0 connectors: | 2 |
| CPU fan connector: | Yes |
| Front panel audio connector: | Yes |
| Number of chassis fan connectors: | 2 |
| BIOS type: | UEFI AMI |
| Cables included: | SATA |
| Supported storage drive interfaces: | M.2, PCI Express 3.0, Serial ATA III |
| RAID levels: | 0, 1, 10 |
| Headphone outputs: | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 4 |
| Microphone in: | Yes |
| PS/2 ports quantity: | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 3 |
| DVI-D ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| VGA (D-Sub) ports quantity: | 1 |
| PCI Express x16 (Gen 3.x) slots: | 2 |
| PCI Express x1 (Gen 2.x) slots: | 2 |
